Product Description

siwitec NYM cable with 3 or 5 wires and 1.5 or 2.5 mm² core cross section in 10, 25, 50 or 100 m length

The siwitec NYM cable is suitable for private as well as industrial and commercial buildings. The NYM cables 300/500V are mainly used for surface-mounted or flush-mounted installations in dry, damp or wet rooms in buildings. The installation of the cable can also be done in concrete, except for shaken concrete, vibrated and mashed concrete. The siwitec NYM cable can also be laid outdoors, provided it is protected from direct sunlight. However, the pipe is not suitable for laying in the soil or water.

Product details:

NYM-J 3 x 1.5 mm². Number of wires: 3 | Cross section: 1.5 mm². Nominal outer diameter: 8.4 mm. Weight: 120 kg/km. Short circuit current (conductor) (1 second): 0.17 kANYM-J 3 x 2.5 mm². Number of wires: 3 | Cross section: 2.5 mm². Nominal outer diameter: 9.6 mm. Weight: 170 kg/km. Short circuit current (conductor) (1 second): 0.29 kANYM-J 5 x 1.5 mm². Number of wires: 5 | Cross section: 1.5 mm². Nominal outer diameter: 9.9 mm. Weight: 170 kg/km. Short circuit current (conductor) (1 second): 0.17 kANYM-J 5 x 2.5 mm². Number of wires: 5 | Cross section: 2.5 mm². Nominal outer diameter: 11.9 mm. Weight 250 kg/km. Short circuit current (conductor) (1 second): 0.29 kA

Standards

General: DIN VDE 0250-204. Conductor: DIN EN 60228. Wire marking: DIN VDE 0293-308. Fire behaviour: DIN EN 50575 Band behaviour: DIN EN 60332-1-2Electrical paramenter: DIN VDE 0298-4 Made in Germany

Technical details:

Cable Type NYM-J Conductor class Class 1 = single wire Ladder material: Copper, blank, round Material wire insulation Polyvinyl chloride (PVC) Outer sheath material: Polyvinyl chloride (PVC) Test voltage Max. 2 kV Conductor temperature Max. 70°C Laying temperature Min. 5°C Ambient temperature Min. -20°C | Max. 50°C CPR fire behaviour Eca Outdoor installation Yes Bending radius (rule) 4D

siwitec Power cable NYM-J 3 x 1.5 mm² | Number of cores: 3 | Cross section: 1.5 mm² | Nominal outer diameter: 8.4 mm | 50 m
Perfect for fixed installation – suitable for installation in surface-mounted or flush-mounted installations in dry, damp or wet rooms as well as in masonry and concrete, except for shaked, vibrated and mashed concrete
Cable features: NYM-J sheathed cable 300/500V | Conductor: copper – blank, round single wire class 1 | PVC outer sheath and core insulation | Ambient temperature fixed installation: -20°C – 50°C | CPR fire behaviour: Eca
Complies with DIN VDE 02050-204 | Conductor DIN EN 60228 | Wire marking VDE 0293-308 | Fire behaviour DIN EN 50575, DIN EN 60332-1-2 | Electrical parameters: DIN VDE 0298-4
Box contents: siwitec cable NYM-J 3 x 1.5 mm², 50 m length
